Evonet: Tunnel Workplace Connector

Evonet is a lightweight Go binary that runs on a target device and connects it to an Evonic server over WebSocket. Once connected, agents can execute bash scripts, Python code, and file operations on that device: without SSH, port forwarding, or a public IP address.

It’s the backend for Tunnel Workplaces. See Workplaces for the Evonic-side setup.

Evonet GUI on macOS

How It Works

Agent (Evonic server) ──── WebSocket (outbound) ──── Evonet (your device)
                                                             │
                                                      bash / python / files

Evonet makes the connection outbound from the device, so the device needs no open inbound ports. Any device that can reach the Evonic server URL works: home networks, corporate firewalls, cloud VMs, Raspberry Pis.

Installation

Download a pre-built binary

Download the binary for your platform from the Evonic releases page:

# Linux (amd64)
curl -L https://your-evonic-server/releases/evonet-linux-amd64 -o evonet
chmod +x evonet
sudo mv evonet /usr/local/bin/

Build from source

Requires Go 1.21+.

git clone https://github.com/anvie/evonic
cd evonet/
make build           # current platform
make build-linux     # Linux amd64
make build-macos       # macOS arm64 + amd64
make build-windows     # Windows amd64
make build-gui-macos   # macOS GUI app (.app bundle) — requires fyne CLI

Quick Start

1. Pair with your Evonic server

In the Evonic UI, open a Tunnel Workplace → click Generate Pairing Code → copy the 6-character code.

On the device:

evonet pair --code X7KQ2M --server https://your-evonic-server.com

2. Connect

evonet run    # auto-reconnect (recommended)

The Workplace status in the UI turns green. Agents assigned to this Workplace can now run commands on the device.

Commands

evonet pair    --code <CODE> --server <URL>   Pair with Evonic server
evonet start                                  Connect (exits on disconnect)
evonet run                                    Connect with auto-reconnect
evonet status                                 Show pairing status
evonet unpair                                 Clear credentials

Options for `start` / `run`

--config <path>    Config file (default: ~/.evonet/config.yaml)
--server <url>     Override server URL
--token  <token>   Override connector token
--workdir <path>   Override working directory

GUI Improvements

Introduced in v0.5.0.

The Evonet GUI has been enhanced for a better user experience:

Clear button — a Clear button in the toolbar lets you clear the current output without restarting the application (#343)
Version in window title — the Evonet version number is now displayed in the application window title, making it easy to verify which version is running
macOS metadata — a FyneApp.toml configuration file provides proper macOS app metadata (app name, version, icon) when building for macOS

Configuration

Config is resolved in priority order (highest wins):

CLI flags
~/.evonet/config.yaml (written by evonet pair)
Config embedded in the binary

server_url: https://your-evonic-server.com
connector_token: tok_abc123...
workplace_id: workplace_xyz
workplace_name: My Server
workspace_path: /home/user/workspace

Running as a Service

systemd (Linux)

[Unit]
Description=Evonet Tunnel Workplace Connector
After=network.target

[Service]
ExecStart=/usr/local/bin/evonet run
Restart=on-failure
RestartSec=5
User=ubuntu

[Install]
WantedBy=multi-user.target

sudo systemctl enable --now evonet

macOS (launchd)

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN"
  "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
  <key>Label</key><string>com.evonic.evonet</string>
  <key>ProgramArguments</key>
  <array><string>/usr/local/bin/evonet</string><string>run</string></array>
  <key>RunAtLoad</key><true/>
  <key>KeepAlive</key><true/>
</dict>
</plist>

launchctl load ~/Library/LaunchAgents/com.evonic.evonet.plist

Embedding Config in the Binary

For distributing a pre-configured Evonet binary (e.g., to a teammate or a server):

# 1. Create config.json
cat > config.json << 'EOF'
{
  "server_url": "https://your-evonic-server.com",
  "connector_token": "tok_abc123...",
  "workplace_id": "workplace_xyz",
  "workspace_path": "/home/user/workspace"
}
EOF

# 2. Build and embed
cd evonet/
make embed CONFIG=../config.json

# 3. Distribute the 'evonet' binary: it auto-connects on 'evonet run'

The JSON config is appended after the binary using a magic marker. It can still be overridden by ~/.evonet/config.yaml or CLI flags.

Security Notes

The connector token is equivalent to a password: protect ~/.evonet/config.yaml with chmod 600.
Pairing codes expire after 5 minutes. They cannot be reused.
exec_bash and exec_python run with the OS privileges of the evonet process. Run Evonet as a dedicated least-privilege user.
All traffic flows over the WebSocket connection authenticated by the connector token (no additional auth per request).
